Product Overview: Automate Your Easel Back Production
For factories producing thousands of frames daily, buying pre-made easel backs adds up. The SJ-FP100 Automatic Back Panel Support Saw allows you to bring this process in-house. It is engineered to cut raw MDF or cardboard strips into finished “Easel Back Supports” (the legs that make a frame stand up) with high speed and precision.
Core Features: Efficiency for Frame Components
01. Dedicated Easel Back Shaping
Unlike general panel saws, the FP100 is purpose-built to cut the specific geometry required for frame supports. It handles the shaping and cutting in a continuous automated cycle.
Unlike general panel saws, the FP100 is purpose-built to cut the specific geometry required for frame supports. It handles the shaping and cutting in a continuous automated cycle.
02. High-Power Dual Motor System
Equipped with a total power of 7.79kW and dual 3kW saw blade motors, this machine cuts through stacks of high-density MDF backboards effortlessly, ensuring clean edges without fraying.
Equipped with a total power of 7.79kW and dual 3kW saw blade motors, this machine cuts through stacks of high-density MDF backboards effortlessly, ensuring clean edges without fraying.
03. Automated Batch Processing
Designed for batch production. Simply load the material plates, and the machine handles the cutting dimensions automatically. It supports cutting plates up to 1220mm in length.
Designed for batch production. Simply load the material plates, and the machine handles the cutting dimensions automatically. It supports cutting plates up to 1220mm in length.
04. Integrated Production Line
This machine is the first step in the “Support Production System.” It is designed to work seamlessly with the SJ-FP200 Dovetail Machine, creating a complete solution for manufacturing professional easel backs.
This machine is the first step in the “Support Production System.” It is designed to work seamlessly with the SJ-FP200 Dovetail Machine, creating a complete solution for manufacturing professional easel backs.
Technical Specifications
| Model | SJ-FP100 |
|---|---|
| Machine Type | Automatic Back Panel Support Cutting Saw |
| Application | Cutting Easel Backs / Frame Stands |
| Max Cutting Length | ≤ 1220mm |
| Max Material Width | ≤ 300mm |
| Bracket Width Range | ≥ 30mm (Small End) |
| Saw Blade Motor | 3 kW × 2 |
| Total Power | 7.79 kW |
| Air Pressure | 0.6 – 0.8 MPa (90-120 psi) |
| Dimensions | 1765 × 1050 × 1310 mm |
Frequently Asked Questions (FAQ)
Q: What material is this machine for?
A: The SJ-FP100 is optimized for cutting MDF (Medium Density Fiberboard) and dense cardboard/hardboard, which are the standard materials for photo frame back panels.
A: The SJ-FP100 is optimized for cutting MDF (Medium Density Fiberboard) and dense cardboard/hardboard, which are the standard materials for photo frame back panels.
Q: Can I use this machine alone?
A: Yes, you can use it to cut the supports. However, to create the “Dovetail” mechanism (the hinge part that connects to the frame back), you will typically need the SJ-FP200 Dovetail Machine to finish the process.
A: Yes, you can use it to cut the supports. However, to create the “Dovetail” mechanism (the hinge part that connects to the frame back), you will typically need the SJ-FP200 Dovetail Machine to finish the process.
Q: Is it suitable for custom framing shops?
A: This is an industrial-grade machine intended for frame manufacturers or component suppliers. For small custom shops, buying pre-made easel backs is usually more cost-effective.
A: This is an industrial-grade machine intended for frame manufacturers or component suppliers. For small custom shops, buying pre-made easel backs is usually more cost-effective.
