Small Positioning Block Corner Cutting Machine Fence – NN36
The small positioning block corner cutting machine fence NN36 is a precision aluminum V-groove guide that attaches to the small fence (靠尺) rail of a corner cutting machine, enabling accurate and repeatable miter-cut positioning for picture frame profiles. Accurate miter cuts are the foundation of professional frame production—even a slight misalignment creates visible gaps at corner joints.
Role in the Corner Cutting Setup
On a corner cutting machine, the fence (靠尺) is the reference surface that frame profiles are positioned against before each cut. The small positioning block corner cutting machine fence NN36 is mounted on this fence rail to act as a positive stop or guide for the profile. By adjusting the block’s position along the fence and locking it with the thumb screw, the operator sets the exact cut length for one side of the frame. Combined with the batch cutting blocks (NN41, NN42), this system enables rapid multi-piece cutting setups.
Specifications
The NN36 aluminum alloy block measures 45mm in height, 60mm in depth, and 80mm in width. The V-groove cut into the body guides the frame profile cleanly and prevents lateral movement during cutting. A black thumb screw on the side clamps the block firmly to the fence rail at any position within the rail’s range. The flat, machined surfaces provide consistent and accurate positioning references.
Comparison With the Large Block (NN37)
The NN36 small positioning block is designed for the small fence (小靠尺) of corner cutting machines—typically used for cutting smaller frame stock or in compact machine configurations. The NN37 large positioning block (大号, 65mm height × 70mm depth × 80mm width) is used with the large fence (大靠尺) for thicker or larger profile sections. Check your machine’s fence rail size before ordering to ensure correct compatibility.
Improving Production Consistency
When cutting frames for production, the small positioning block corner cutting machine fence NN36 eliminates the need to measure and mark each piece individually. Once the block is set and locked, every cut at that position produces identical length pieces. This dramatically improves output quality consistency and reduces material waste from measurement errors.
Compatible Accessories
Use the NN36 with the batch cutting blocks (NN41 small or NN42 large), the wood support strip (NN38), and the transparent safety guard (NN39 or NN40) for a complete, safe, and efficient corner cutting machine setup. All accessories are available from XKY Framing.
Order the NN36 small positioning block corner cutting machine fence from XKY Framing today and achieve precise, repeatable miter cuts for professional frame production.
