The highest-capacity stainless steel concealed hanger in the XKY range at 20 kg, with four mounting holes and an extra-wide 32 mm body – the premium choice for heavy mirrors, bathroom shelving, and commercial displays.
The highest-capacity stainless steel concealed hanger in the XKY range at 20 kg, with four mounting holes and an extra-wide 32 mm body – the premium choice for heavy mirrors, bathroom shelving, and commercial displays.
| Specification | Value |
|---|---|
| thickness | 1.0 |
| weight | ~12 (est.) |
| over all length | 66 |
| over all width | 32 |
| bow/arch height | 6 |
| key hole slot length | 11.5 |
| key hole slot width | 6.5 |
| screw hole diameter | 3.5 |
| no.of screw holes | 4 |
| max load capacity | 20 |
| color | Silver (brushed) |
Two O09 hangers can theoretically support 40 kg combined; practically, we recommend a maximum of 25–30 kg with all four holes anchored to studs or masonry.
Use M4 × 30 mm stainless steel hex-head screws into wall studs, or M4 × 50 mm stainless steel with 60 kg-rated toggle anchors for drywall without studs.
Yes – this is one of the most popular applications; the stainless construction handles steam and moisture while the 20 kg rating supports loaded shelves with toiletries.
