Product Overview: The Solution for Seamless, Nail-Free Framing
Not every frame can be nailed. For delicate mouldings, shadow boxes, or high-end gallery frames requiring a flawless finish, the MM100 Frame Assembly Machine is the answer. Instead of V-nails, it relies on precision pneumatic pressure to hold the frame together while the adhesive cures, creating a bond that is often stronger than the wood itself.
Core Features: Precision Quad-Clamping
01. Quad-Directional Simultaneous Pressure
Unlike standard clamps that require manual tightening, the MM100 uses four synchronized pneumatic cylinders to press all four sides of the frame inward at once. This 3D positioning clamping ensures the frame is perfectly square and flat in seconds.
Unlike standard clamps that require manual tightening, the MM100 uses four synchronized pneumatic cylinders to press all four sides of the frame inward at once. This 3D positioning clamping ensures the frame is perfectly square and flat in seconds.
02. Seamless Joining Accuracy
Designed for precision, the machine achieves an assembly accuracy of 0.02mm, with joint gaps less than 0.1mm. This eliminates the “open corners” often seen in manual assembly.
Designed for precision, the machine achieves an assembly accuracy of 0.02mm, with joint gaps less than 0.1mm. This eliminates the “open corners” often seen in manual assembly.
03. Rapid Production Cycle
Optimized for use with quick-dry adhesives (such as UV or AB glues). The steady pneumatic pressure allows for ultra-fast curing times (5-30 seconds), significantly speeding up the batch production of smaller frames.
Optimized for use with quick-dry adhesives (such as UV or AB glues). The steady pneumatic pressure allows for ultra-fast curing times (5-30 seconds), significantly speeding up the batch production of smaller frames.
04. Wide Adjustment Range
The modular structure allows for infinite adjustment to fit frame sizes ranging from 10cm up to 60cm, making it a versatile tool for photo frames, mirror frames, and decorative art.
The modular structure allows for infinite adjustment to fit frame sizes ranging from 10cm up to 60cm, making it a versatile tool for photo frames, mirror frames, and decorative art.
Technical Specifications
| Model | SM-MM100 |
|---|---|
| Machine Type | Pneumatic Frame Assembly Machine / Clamp |
| Clamping Method | Quad-Directional (4-Side) Pressure |
| Processing Range (Min-Max) | 100mm × 100mm to 600mm × 600mm |
| Max Frame Thickness | 100mm (10cm) |
| Air Pressure | 0.6 – 0.8 MPa (90-120 psi) |
| Power Supply | 220V / 380V |
| Machine Dimensions | 1000 × 850 × 850 mm |
| Net Weight | 100 kg |
Frequently Asked Questions (FAQ)
Q: Is this machine a V-Nailer?
A: No. The MM100 is a clamping and assembly machine designed for glue-joining. It does not drive nails. If you need a machine that drives V-nails, please see our NN Series (NN300/400).
A: No. The MM100 is a clamping and assembly machine designed for glue-joining. It does not drive nails. If you need a machine that drives V-nails, please see our NN Series (NN300/400).
Q: Why use a glue assembly machine instead of a nailer?
A: Some hard woods, very thin profiles, or specific gallery designs cannot be nailed without splitting. Glue joining with high pressure (like the MM100 provides) creates a seamless, museum-quality finish without visible nail holes.
A: Some hard woods, very thin profiles, or specific gallery designs cannot be nailed without splitting. Glue joining with high pressure (like the MM100 provides) creates a seamless, museum-quality finish without visible nail holes.
Q: What frame sizes can it handle?
A: It is optimized for small to medium frames, specifically those within the 10cm to 60cm range. This covers most standard photo frame sizes (4×6″ up to 20×24″).
A: It is optimized for small to medium frames, specifically those within the 10cm to 60cm range. This covers most standard photo frame sizes (4×6″ up to 20×24″).
