Product Overview: The Heavy-Duty Solution for Aluminum & Wood
While standard saws struggle with hard metals, the CT400 PRO Pneumatic Miter Cutter excels. Designed with a stationary table and a forward-moving blade, it minimizes vibration, making it the ideal machine for cutting Aluminum Alloy, thick solid wood, and PVC profiles. If you need razor-sharp corners for metal frames or windows, this is your machine.
Core Features: Precision Engineering
01. “Blade-Forward” Fixed-Table Design
Unlike traditional drop-saws where the table or head might wobble, the CT400 keeps the table perfectly static while the blade moves forward on precision guide rails. This guarantees smooth, burr-free cuts on hard materials.
Unlike traditional drop-saws where the table or head might wobble, the CT400 keeps the table perfectly static while the blade moves forward on precision guide rails. This guarantees smooth, burr-free cuts on hard materials.
02. Auto-Pneumatic Clamping Safety
Safety is built-in. The intelligent system automatically clamps the workpiece with pneumatic cylinders before the blade engages. This prevents the dangerous “kickback” often associated with cutting aluminum manually.
Safety is built-in. The intelligent system automatically clamps the workpiece with pneumatic cylinders before the blade engages. This prevents the dangerous “kickback” often associated with cutting aluminum manually.
03. Extreme Cutting Precision (±0.05mm)
Powered by a robust copper motor and anti-burr seal strips, the machine achieves a cutting tolerance of just ±0.05mm. Zero corner chipping means less rework and higher profit margins.
Powered by a robust copper motor and anti-burr seal strips, the machine achieves a cutting tolerance of just ±0.05mm. Zero corner chipping means less rework and higher profit margins.
04. Multi-Angle Versatility
Precision-engineered for creating various frame shapes. It easily adjusts to 90°, 45°, 67.5°, and 60°, perfect for quadrilateral, hexagonal, and octagonal frames.
Precision-engineered for creating various frame shapes. It easily adjusts to 90°, 45°, 67.5°, and 60°, perfect for quadrilateral, hexagonal, and octagonal frames.
Technical Specifications
| Model | SC-CT400 PRO (Pneumatic) |
|---|---|
| Machine Type | Single Head Pneumatic Miter Saw |
| Cutting Mechanism | Moving Blade / Fixed Table (Adjustable Speed) |
| Cutting Angles | 90°, 45°, 67.5°, 60° |
| Blade Size | 10″ – 12″ (Inch) |
| Processing Range | 160mm (W) × 100mm (H) |
| Power | 2.2 KW |
| Air Pressure | 0.6 – 0.8 MPa |
| Dimensions | 750 × 750 × 800 mm |
| Net Weight | 130 kg |
Frequently Asked Questions (FAQ)
Q: Can the CT400 PRO cut Aluminum?
A: Yes, absolutely. The Fixed-Table design makes it significantly more stable than standard chop saws, which is critical for cutting aluminum profiles cleanly without vibration marks.
A: Yes, absolutely. The Fixed-Table design makes it significantly more stable than standard chop saws, which is critical for cutting aluminum profiles cleanly without vibration marks.
Q: What is the difference between CT300 and CT400?
A: The CT300 focuses on Dust Extraction (ideal for wood/MDF dust). The CT400 PRO focuses on Structural Stability and Pneumatic Power (ideal for cutting harder materials like aluminum or heavy hardwoods).
A: The CT300 focuses on Dust Extraction (ideal for wood/MDF dust). The CT400 PRO focuses on Structural Stability and Pneumatic Power (ideal for cutting harder materials like aluminum or heavy hardwoods).
Q: Is it safe to operate?
A: Yes. The blade remains retracted inside the housing until the pneumatic clamps have secured the material. This “Hands-Free” clamping significantly reduces the risk of operator injury.
A: Yes. The blade remains retracted inside the housing until the pneumatic clamps have secured the material. This “Hands-Free” clamping significantly reduces the risk of operator injury.
