The XKY-M18 aluminum frame top support is specifically engineered for modern aluminum and metal picture frames. The 43mm ABS bracket is designed to accommodate the thinner, more precise profiles typical of metal framing, providing a secure and flush mount with a 15mm nail.
| Specification | Value |
|---|---|
| materia | ABS Engineering Plastics |
| nail length | 15mm |
| nail thickness | 1.2mm |
| main body dimensions | 43mm x 39mm |
While the XKY-M18 is specifically designed and optimized for aluminum and metal picture frames, it can also be used with other thin-profile frames as long as the bracket dimensions are compatible.
The XKY-M18 itself is made from ABS engineering plastics. Despite the 'aluminum frame' in its name, the bracket material is ABS — it is designed to support aluminum frames, not made from aluminum.
The nail length is 15mm and the nail thickness is 1.2mm. The thinner nail is consistent with the lighter weight of aluminum frames compared to heavier wooden frames.
The XKY-M18 spans 43mm overall, providing a good contact area for modern aluminum frame profiles while remaining unobtrusive.
The XKY-M18 is specifically profiled and dimensioned to fit the thinner, more precise geometry of aluminum frames, whereas standard top support brackets like M14 and M15 are designed for wider wooden moulding profiles.
