Product Overview: ST-NN500 PRO
The ST-NN500 PRO combines heavy-duty construction with modern digital control. Featuring a responsive LCD touchscreen and a powerful pneumatic active clamping system, it delivers intelligent, high-speed CNC nailing for professional frame assembly.
Core Features: Smart Framing with NN500 PRO
- Intelligent Touchscreen Control
Upgraded from the standard NN400, the NN500 features a responsive LCD touchscreen. This allows operators to input nail positions visually, store frame data, and switch between profiles instantly without manual recalibration. - Active Clamping System (Downward Pressure)
Features a powerful pneumatic cylinder that applies active downward pressure. This ensures the frame corner is held firmly against the table before nailing, eliminating gaps even on warped wood. - High-Speed CNC Nailing
Driven by a nine-stage CNC system, it can perform 5-nail stacking and 9-row synchronized nailing in one pass. This flexibility handles complex moulding shapes with ease. - Multi-Material Versatility
The smart pressure adjustment makes it suitable for joining solid wood, MDF, foam, and plaster molding strips without damaging delicate surfaces.
Technical Specifications
| Specification | Details |
|---|---|
| Model | ST-NN500 PRO |
| Operation Type | Touchscreen CNC + Pneumatic Active Clamping |
| Max Frame Width | 130mm (13cm) |
| Max Frame Thickness | 100mm (10cm) |
| V-Nail Compatibility | 5mm, 7mm, 10mm, 12mm, 15mm |
| Air Pressure | 6-8 kg/cm² (90-120 psi) |
| Joining Angles | 90°, 120°, 135° |
| Packing Dimensions | 800 × 700 × 1300 mm |
Frequently Asked Questions (FAQ)
Q: What is the main upgrade of NN500 compared to NN400?
A: While both machines use the stable “Active Clamping” system, the NN500 adds a Touchscreen interface. This allows you to save frame settings and visualize the nailing process, whereas the NN400 relies on standard controls.
A: While both machines use the stable “Active Clamping” system, the NN500 adds a Touchscreen interface. This allows you to save frame settings and visualize the nailing process, whereas the NN400 relies on standard controls.
Q: Does it support stacking nails for tall frames?
A: Yes, the NN500 supports multi-layer stacking (up to 5 nails per position). This is essential for joining tall or heavy frames securely.
A: Yes, the NN500 supports multi-layer stacking (up to 5 nails per position). This is essential for joining tall or heavy frames securely.
Q: Is the interface difficult to learn?
A: No, the CNC system is designed for “One-Button Start.” Most operators can master the touchscreen interface within 30 minutes.
A: No, the CNC system is designed for “One-Button Start.” Most operators can master the touchscreen interface within 30 minutes.
