Plastic Wire Turn Button Clip Yellow – U30 Complete Guide
The Plastic Wire Turn Button Clip Yellow (SKU: U30) is a specialised ABS fastener that combines backing board retention with an integrated wire routing channel. The bright yellow body provides high visibility in installation environments, while the 2 mm wire channel allows picture hanging wire to pass directly through the clip body for streamlined, clean-wire signage and poster frame assemblies.
Why Choose the Plastic Wire Turn Button Clip Yellow?
Traditional backing clips require separate wire attachment hardware on the frame back. The U30 Plastic Wire Turn Button Clip Yellow integrates both functions — it locks the backing board AND routes the hanging wire — reducing hardware count and simplifying the assembly process for signage, restaurant menu frames, and retail poster displays.
Key Dimensions
Total length: 18 mm. Head width: 7 mm. Tail: tapered. Wire channel diameter: 2 mm. Body thickness: 1.5 mm. Material: yellow ABS.
Installation
Thread picture wire through the 2 mm tail channel before installation. Position clip over pilot hole. Fasten with 2 mm screw or brad nail. Rotate to lock backing board. Wire is routed and retained simultaneously.
Related Products
For black wire clip see U31 Plastic Wire Turn Button Clip Black. For large clear see U29 Large Clear Plastic Turn Button Clip.
Material & Finish
High-visibility yellow ABS, 1.5 mm body, 2 mm integrated wire channel.
FAQ
Q: What wire size fits the channel?
A: Up to 1.5 mm diameter. Standard 1 mm galvanised picture wire passes through easily.
Q: Why yellow?
A: High-visibility for quick identification in signage swap systems and multi-panel displays.
Q: Can U30 be used without routing wire?
A: Yes — the 2 mm hole works with a standard brad nail for conventional backing retention.
